FMD 1204
FMD1204: High-Performance Chinese FARM Tractors
For farmers looking for high-performance, durable, and cost-effective chinese farm tractors. the FMD1204 wheeled tractor is an ideal choice. Manufactured by FMD, a leading name in China farm tractors, this model combines strength, efficiency, and modern technology to deliver exceptional agricultural results.
Designed to handle various farm operations, including plowing, seeding, and hauling, the FMD1204 is equipped with a robust YTO engine, a reinforced chassis, and an advanced transmission system. This ensures optimal performance, fuel efficiency, and durability, making it one of the most sought-after Chinese farm tractors in the market today.
Built for Strength, Durability, and Efficiency
The FMD1204 wheeled tractor is engineered with a sturdy TD chassis that provides enhanced stability and strength, allowing it to operate seamlessly in varied terrains and demanding agricultural conditions. Its meshing sleeve transmission (16+8 gears) ensures smooth gear shifting and precise control, making farm operations more efficient.
With a minimum ground clearance of 380 mm, the FMD1204 navigates rugged fields with ease, reducing potential damage to crops and soil. Additionally, its large-diameter tires (13.6-24 front, 16.9-34 rear) offer superior traction, ensuring stability in wet, muddy, or uneven conditions.
Key Features
- High-Powered YTO Engine – The turbocharged intercooled inline engine delivers 88.3 kW of rated power, ensuring high torque and low fuel consumption, making it an efficient and economical choice for farmers.
- Advanced Transmission System – The 16+8 gear meshing sleeve transmission allows for seamless speed adjustments, ensuring optimal performance for different farm tasks.
- Dual-Speed PTO (540-1000 RPM) – Enhances compatibility with various farming equipment, maximizing operational efficiency.
- Hydraulic Steering System – Provides effortless maneuverability, reducing operator fatigue during long working hours.
- Heavy-Duty Chassis and Tires – Designed for durability and stability, ensuring superior grip and balance on all farming terrains.
- Spacious Cab with Modern Amenities – Features air conditioning, a sound system, a reversing camera, centralized controls, and a sunshade, ensuring maximum operator comfort.
- Hydraulic Output System – Comes with two sets of hydraulic outputs, improving versatility for various agricultural attachments.
- Large Fuel Capacity – With a main 150L tank and an auxiliary 60L tank (totaling 210L), the FMD1204 supports extended working hours without frequent refueling.
- High Traction Power – With a maximum traction force of ≥21.2 kN, the FMD1204 easily handles heavy loads and difficult field conditions.
- Enhanced Safety Features – Equipped with an air pump for dual-circuit pneumatic braking, ensuring reliable stopping power under heavy loads.
Designed for Maximum Comfort and Ease of Operation
Farming requires long hours of operation, and the FMD1204 ensures operator comfort with its ergonomic seat, intuitive dashboard, and flat-floor design. The spacious cab offers enhanced visibility and modern controls, making it easy to handle even the most demanding tasks.
Additional features such as a reversing camera, an advanced ventilation system, and a centralized control panel provide a more enjoyable and efficient working experience. The soft shaft control further enhances precision, making field operations smoother and more effortless.
FMD 1204 Specifications
General Specifications
External Dimensions (L x W x H): 4700 × 2120 × 3080 mm
Wheelbase: 2550 mm
Front Wheel Track Width: 1610 mm
Rear Wheel Track Width: 1630 mm
Minimum Ground Clearance: 380 mm
Transmission & Drivetrain
Transmission Gears (Forward/Reverse): 16 + 8
Speed Range:
- Forward: 1.49 – 31.50 km/h
- Reverse: 2.29 – 29.25 km/h
Transmission Shifting Method: Meshing sleeve
Tire Specifications:
- Front: 13.6-24
- Rear: 16.9-34
Maximum Traction Force: ≥21.2 kN
Engine Specifications
Engine Model: LR6B5-23
Engine Type: Inline, water-cooled, turbocharged intercooled
Rated Power: 88.3 kW
Rated Speed: 2200 r/min
Power Take-Off (PTO) Specifications
PTO Type: Rear independent
PTO Speed (r/min):
- Standard: 760 / 850
- Optional: 540 / 1000
PTO Power: ≥75.1 kW
Versatility & Customization Options
The FMD1204 wheeled tractor is highly adaptable, with multiple modification options to cater to diverse agricultural needs. This model can be upgraded with:
- Front lifting device for enhanced lifting capabilities.
- Front excavator attachment for additional digging applications.
- Front drilling and grabbing features for handling various farming and construction tasks.
- Customizable tire options to match specific terrain requirements.
This level of flexibility makes the FMD1204 an invaluable asset for farms of all sizes, capable of handling multiple tasks with a single powerful machine.
Looking for Top-Notch Chinese Farm Tractors?
- Superior Quality at an Affordable Price – Manufactured in China by FMD, a trusted name in Chinese tractors, this model delivers premium performance at a cost-effective price.
- Highly Fuel-Efficient – The advanced YTO engine design ensures lower fuel consumption while delivering maximum power output.
- Built for Reliability – Constructed with high-strength materials, the FMD1204 guarantees longevity even in the toughest working conditions.
- Versatile Farming Applications – Whether used for plowing, seeding, tilling, or transportation, the FMD1204 excels in every aspect of modern agriculture.
- Advanced Safety and Comfort – Equipped with dual-circuit braking, air conditioning, and an ergonomic design, this tractor ensures operator safety and ease of use.
Order Your FMD1204 Wheeled Tractor Today
For those searching for high-quality, powerful, and reliable tractors for farming, the FMD1204 wheeled tractor stands out as the best choice. With its cutting-edge features, robust build, and cost-effective pricing, this tractor is a valuable investment for any modern farm.
Contact us today to learn more about pricing, specifications, and delivery options. Upgrade your farm with the FMD1204 wheeled tractor and experience the difference in power, efficiency, and reliability!
